FH580V-S20-S

19hp Kawasaki FH Series Engine, Vertical 1"x3-5/32" Shaft, Electric Start, 15 Amp Alternator, Right Side Muffler (Oil Filter Side)
$1,889.00 MSRP: $1,997.45
QuantityPrice

OUT OF STOCK

When out of stock, this item is subject to the Kawasaki Replacement Engine Program. Call for details.

Need Help? Call 800-321-6725
Standard Shipping Charge: $159.99
(Charge for continental US. Other options at checkout.)

Item Specifications

Item Specifications

  • Kawasaki FH Series
  • 19hp
  • FH Series
  • Oil Filter & KAI Air Filter
  • Valve Type: Overhead Valve
  • Sleeved Bore: Yes
  • Mounting: Vertical
  • Engine Displacement (cc): 585
  • Starter Type: Electric Start
  • Alternator: 15 Amp
  • Fuel Pump: Yes
  • Shaft Size: 1"Dx3-5/32"L
  • Muffler: Right Side
  • Length: 14.25"
  • Height: 16.7"
  • Width: 14.5"
  • Shipping Rate Weight: 151.0
  • Product Condition: New
  • Warranty: 3-Year Manufacturer's Warranty

Notes and Warnings
  • Bendix Starter
  • The gross power rating is measured in accordance with SAE J1995 at 3600 rpm (without the muffler and air filter in place). Torque values are derived at 2600 rpm. Actual power output for the engine installed in the final machine will vary depending on numerous factors, including the operating speed of the engine in application, environmental conditions, maintenance, and other variables.

Replaces These Items
  • Kawasaki: FH580V-AS20S;FH580V-BS20S;FH580V-CS20S;FH580V-DS20S;FH580V-ES20S;FH580V-FS20S;
